Enhancing Urban–Rural Connectivity through Transport Hubs

The Korea Train Express (KTX) and express buses have expanded to reach more areas in the Republic of Korea. Yet, a bias for cars for regional trips was still high due to a lack of transport connectivity and transfer systems.

According to a KOTI questionnaire survey in 2012, more than 50% of respondents considered poor accessibility of the KTX stations and the inconvenient transfer system as primary factors in not using the mass transit. More than 65% of passengers use private cars or taxis to reach the Chunan-Asan KTX station and Gwangmyung KTX station.

Transfer distances at rail stations and bus terminals in the Republic of Korea were at an average of 357.9 meters and 227.6 meters respectively.  Yet, rail stations and bus terminals lacked moving walkways, escalators, and elevators.

Longer travel time was also a problem for express buses due to a large number of transport systems. The lack of synchronization of time schedules between the main and feeder lines increased waiting time, and in turn, added to total travel time.

Physical integration of the public transportation network is essential to convince people to shift to public transport use. It involves the development of transport connectivity and transfer facilities to provide convenient transfers among different transport modes. This can be achieved through the establishment of a transport hub, a complex of transfer facilities that combines rail stations, bus depots and terminals, ticketing booths and passenger facilities, transfer paths, and other facilities. Passengers are guaranteed connectivity at transport nodes, where transfer frequency is higher between such modes as subways, buses, taxis, cars, and bicycles.

For regional trips, interchange stations can be in the form of super-hubs, hubs, and sub-hubs, depending on the roles and functions of each node where transport connectivity and transfers occur. A super-hub can be developed at the KTX station, while bus terminals and rail stations in large cities can be developed as transfer hubs.

Physical integration has been implemented at the Dongdaegue KTX station that is located 282 kilometers from the Seoul KTX station. It became a super-hub after six scattered bus terminals were relocated in front of the KTX station, reducing the transfer distance between the KTX station and the bus terminals. Several bus terminals and highway rest areas have also become sub-hubs that facilitate transport connectivity and transfer among the different transport modes. A comprehensive plan for the development of super-hub and sub-hubs is revisited every five years.

Expressway transfer centers have been operating in the Republic of Korea since 2009. These are park and ride areas located near subway stations and function more as parking garages rather than transfer facilities. Because the locations did not take into account commuter experience, transfer centers lacked services such as coordinated feeder lines, time scheduling, and reservation systems.

In Seoul, reforms in the public transport system that began in 2004 included the establishment of bus transport stations that provide convenient transfers among public transport modes. The four major transfer centers in Seoul improved transfer convenience among public transport modes through a system that integrated the KTX, buses, and subways, as well as connected exclusive median bus lanes near the station. These centers served to create eco-friendly and pedestrian priority spaces as well.

Interchange stations can also be established at rest areas on major express highways. Inter-regional buses from around the country stop at certain rest areas on major express highways before dispersing to their final destinations. Intercity, or inter-regional, bus lines could improve rest stops by providing refreshments for passengers and brief maintenance for vehicles. If passengers could transfer from one line to another, they could take advantage of such transfer centers. Six transfer centers located at the Gyeongbu, Honam, and Yeongdong expressway corridors have been installed and are operating successfully.

The physical integration of the public transport network is considered as one of the most important factors of seamless transport. Measures essential to its implementation are:

1. A comprehensive master plan for physical integration, based on a detailed field survey on transfer facilities;
2. A hub-like transfer facility, based on the master plan, and improvement of facilities;
3. Operation and management center for facilities; and
4. Improvement in law and principles related to development of transfer hubs.

As implemented at the Dongdaegue KTX Station, physical integration can be achieved by i) relocating bus terminals near the train station to secure as many feeder lines as possible; ii) coming up with specific designs and arrangements for transfer facilities and bus stops, and iii) eliminating unnecessary waiting periods through the appropriate scheduling of arrival and departure times.

Meanwhile, physical integration for expressway transfer centers may be implemented by increasing the number of transfer centers on expressways and on national highways; and by improving transfer centers to give access to, and from, local bus, taxi, and other feeder lines.

International Transport Forum and Korea Transport Institute. 2013. Seamless Public Transport for All: Proceedings of a Joint Seminar held in Paris, France on 6 March 2012.

Y. Kwon, ed. 2017. New Intermodal Transport Systems. Sejong: The Korea Transport Institute.

Development Asia. Giving Public Transport a Push through Seamless Travel.
